The GYS Spot welder range guarantees panel beaters a superior quality Spot Welder manufactured to the highest standards in Europe. Our Spot welder range includes their latest automatic Inverter PTI Evolution S7. The GYS Spot Welder range includes multiple OEM approvals.

GYS EVOLUTION AUTOMATIC INVERTER SPOT WELDER

High Strength steel spot welder which can operate at just 16-25 amps



PRODUCT FEATURES

Automatic as well as manual function C Gun
14,500 amps welding current
Liquid cooled all the way to the welding caps
Clamping Force of 550 daN at 8 Bar
Remote control on C Gun Handle
SD Card for weld quality reporting
Low Electrical Consumption



KIT CONTAINS

1 X Evolution Balancing System Spring Balancer & Mast
1 X Gyspot Evo Pti S7 6M
1 X Gyspot protection Cover
1 X Single Side Gun
1 X C10 Arm
1 X Gyro 360 Arms C Pti
1 X Gys 50044 Set Of 5 C Arms
1 X Gys Evolution Parts Box

Ready to find out more?

GYS Evo Welder

GYS SPOT INVERTER  WELDER

The onboard intelligence guarantees full automation, offering body shops the ability to increase their efficiency: Genius G-clamp with pneumatic over-opening, easy arm positioning without adjustment, motorised overhanging arm providing a wide working area.

It is the most advanced machine for the active body shop. It is the most advanced machine for the active body shop.

Performance:

  • Light weight of 11.3 kg with the G1 arm.
  • 80 mm of automatic opening capacity (20 mm at rest)
  • Manual over-opening of the arm for access to difficult areas (200 mm release).
  • Brass clamp support and arm-base for an optimal electrical contact (effortless maintenance).
  • The double-action feature ensures quick arm removal without the use of tools.
  • Automatic cooling connection.
  • Remote-controlled clamp (opening, welding, adjustments validation).
  • Lockable Gyrosocope, ball bearing, integrated into the clamp body.
  • High duty cycle (18 points/min).
  • Optional G9 arm is suitable with auto mode.
  • Optional single-point gun (option)



Kit Includes

1 x SET OF 3 G ARMS INSULATED G2+ G3 + G4
1 x GYSPOT INVERTER PTI.G 400V 6M
1 x GYSPOT PROTECTION COVER
1 x BALANCING SYSTEM G ADJUSTABLE CABLE
1 x MONO-POINT PTI-G GUN KIT
6 x LONG LIFE CONC. GREEN COOLANT 5LTR
1 x 3P 4 PIN 32 AMP ANGLE PLUG
1 x GYS EQUIPMENT SIGN

GYSPTIG.TAG.0

Ready to find out more?

You can Compare these Spot Welders here with our handy GYS Spot Welder Comparison Table

GYS 100RC INVERTER SPOT WELDER

The GYSPOT 100R-C is an air cooled Inverter spot welder. This spotter allows the welding of galvanized steels and high strength steels. The clamping force to the electrodes can reach 300 daN and the effective welding current can reach 10 000 A (R.M.S. value). Welder has the traceability of welding spots.

User friendly: Large display (6”), with intuitive menus
Saving welding parameters
Easy: Only 2 parameters to select (thickness and steel sheet type)



Performance:

High welding current 10 000 A
Digital display of the actual current value
Sound alert if the welding current is too low
Constant current control
Electrode force control
Digital display of the actual electrode arms force
High clamping force: 300 daN at 7 bar
Sound alert if the actual clamp force is too low
Record on SD card of the characteristics of each welding spot performed
Restoration on any PC of the reports saved on the SD card



Kit Includes

Ideal clamp for all types of metal works
Lightweight and easy to handle: Weight: 4 kg (with C1 arm).
Single-sided welding tool with 3 m cable:
Spot slide hammer welding, stud/rivet/ring welding, carbon shrinking
Accessory box
Support cable bracket with a telescopic arm
Control display 6

GYS100RC
